Al Ani AH; AlBadra MYR; Al Kaisy S; Abdulmoneim H; Abdulhakim H; Al jowher Z; Ahmed EE; Al Khalid G

Special Article – General Surgery

Ann Surg Perioper Care. 2017; 2(3): 1030.

Left Hepatic Lobe Herniating Through Sternotomy Incision

Al Ani AH¹*, AlBadra MYR², Al Kaisy S¹, Abdulmoneim H¹, Abdulhakim H¹, Al jowher Z², Ahmed EE¹ and Al Khalid G¹

¹Department of General Surgery, Sheikh Khalifa Medical City, Sheikh Khalifa General Hospital, Ajman, United Arab Emirates

²Department of Diagnostic Radiology, Sheikh Khalifa Medical City, Sheikh Khalifa General Hospital, Ajman, United Arab Emirates

*Corresponding author: Amer Hashim Al Ani, Department of General Surgery, Sheikh Khalifa Medical City, Sheikh Khalifa General Hospital, Ajman, United Arab Emirates

Received: October 04, 2017; Accepted: November 02, 2017; Published: November 09, 2017

Abstract

Introduction: Liver herniation through surgical incision is very rare. Moreover, it is exceptional for the left hepatic lobe to herniate through sternotomy incision.

Presentation of the case: We present herein a 66 year old woman admitted to ER complains about upper abdominal pain. Abdominal CT scan showed herniation of part of left hepatic lobe through previous sternotomy incision. Conservative measures were successful in managing her symptoms.

Discussion: Till now only few cases of liver herniation through scar of sternotomy have been documented.

Conclusion: Although it is rare, left hepatic lobe may herniate through sternotomy incision.

Keywords: Left lobe liver; Sternotomy; Incisional hernia

Introduction

It is very rare for a liver or part of it to be involved in a hernia .Congenital and traumatic diaphragmatic hernias are the most common hernias to contain liver [1,2]. Only few cases of liver herniated through incision of sternotomy were documented in medical literatures [3]. Asymptomatic cases were treated conservatively [3]. While those with symptoms were treated by surgery to repair the hernia and reduce its content (liver) [4].

Case Presentation

We report a 66 year old women presented to ER with upper abdominal pain following heavy meal. The pain was burning in nature, radiates to the back. Associated with nausea. There was no vomiting, fever, chills, or itching. She noticed no changes in her bowel habit, color or consistency. She identified a non-painful swelling protruded from her upper abdomen 2 years ago. She is asthmatic, diabetic, had history of myocardial infarction. Three years back she had Coronary artery bypass grafting (CABG). She is on aspirin, amlodipine, frusemide, Insulin and nebulizer. She is not smoker. Not drinking alcohol.

On examination

She was pale, not jaundiced. Her vital signs were within normal. By inspection; there was a scar of previous sternotomy extending from the chest to upper part of abdomen. A 6X6 centimeters mass was protruding from the scar. The mass was soft by palpation. It was not tender .The rest of the abdomen was soft, apart from mild tenderness in epigastric region. Bowel sounds were active.

Laboratory tests revealed

Low Hemoglobin (9.80gm/dl), low serum iron (5.90umol/l), high blood sugar (7.8mmol/l ), high blood Urea (10.70mmol/l), low Albumin (30.0gm/l), low serum Calcium ( 2.09mmol/l), normal T4 Free (15.82pmol/l), low T3 Free (3.52pmol/l), high TSH (4.64mIU/l), high D-Dimer (1.30mg/l), high Hemoglobin A1c (8.1%), high C reactive protein (19.9mg/l), normal liver function test, normal lipase and amylase. Serum electrolytes were within normal. All the abnormal parameters were corrected. ECG, Echocardiography was done for the patient. Then her cardiac problems were managed by the cardiologist. OGD (esophagogastroduodenoscopy) showed reflux gastritis. This was controlled by proton pump inhibitors.

Computed tomography abdomen revealed herniation of the left lobe of the liver (Figure 1 and 2) with surrounded fat through a large epigastric defect just below a previous sternotomy incision (Figure 1 and 2). The herniated part appear iso-dense to the normal liver. Severe intervertebral disc generation seen with possibility of multiple disc prolapse.

Figure 1: Plain chest x ray showing median sternotomy closure with interrupted stainless steel wires.



    Figure 1:  Plain chest x ray showing median sternotomy closure with
interrupted stainless steel wires.

Figure 2: Sagittal CT scan image (arterial phase) revealed herniation of the left lobe of the liver (white asterisk) with surrounded fat through a large epigastric defect just below a previous sternotomy incision (white arrow).



    Figure 2:  Sagittal CT scan image (arterial phase) revealed herniation of
the left lobe of the liver (white asterisk) with surrounded fat through a large
epigastric defect just below a previous sternotomy incision (white arrow).

After two days of conservative management in hospital, her pain was relieved, her blood sugar was controlled, and her parameters were good. She was discharged home in a good general condition. For the next three months patient was asymptomatic.

Figure 3: Axial CT scan image (venous phase) shows the herniated liver parenchyma through the epigastric anterior abdominal wall defect, the herniated part appear isodense to the normal liver.



    Figure 3:  Axial CT scan image (venous phase) shows the herniated liver
parenchyma through the epigastric anterior abdominal wall defect, the
herniated part appear isodense to the normal liver.

Figure 4: Incisional hernia through sternotomy incision.



    Figure 4:  Incisional hernia through sternotomy incision.

Discussion

Liver hernia is very rare [1,5] Table 1 [5]. Congenital diaphragmatic defects, and blunt trauma diaphragmatic rupture are the most common documented causes resulting in this hernia [2]. Obesity and previous abdominal surgery are other less common causes [6].

Table 1: Cases of liver incisional herniation from 2000 to 2015 [5].





    Year (reference)
    Age (sex)
    Complaint
    surgery
    Duration (year)
    Herniating lobe of liver
    Therapy


    2000 (3)
    56 (f)
    Right upper quadrant pain of 6 months duration
    No
    -
    Left lobe (through the rectus muscle)
    conservation


    2009 (4)
    48 (m)
    Discomfort and swelling in the epigastrium    during 3 weeks
    Coroner artery bypass surgery
    2
    Left lobe
    conservation


    2012 (5)
    81 (m)
    Acute right upper quadrant abdominal pain
    Coroner artery bypass surgery
    7
    Left lobe
    conservation


    2004 (6)
    45 (f)
    Upper abdominal pain of 3 months duration
    Liver transplantation
    2
    Left lobe
    conservation


    2005 (7)
    73 (f)
    Right upper quadrant pain of 1 week duration
    (1) Cholecystectomy
    6
    Left lobe
    conservation


    (2) Ileus*
    4


    2012 (8)
    70 (f)
    Right upper quadrant pain of 4 months duration
    Cholecystectomy
    20
    Left lobe
    Surgery


    2014 (9)
    75 (f)
    Right upper quadrant pain of 6 months duration
    (1) CC
    5
    Left lobe
    conservation


    (2) cystectomy
    5


    2015 (present case)

    Epigastria pain of 1 year duration
    Coroner artery bypass surgery
    3
    Left lobe
    conservation



Table 1: Cases of liver incisional herniation from 2000 to 2015 [5].

Up to May 2015 only three cases have been reported for liver herniation through scar of previous of CABG surgery as in this case.5

Abdominal pain, discomfort, nausea, vomiting, jaundice, dyspnea, confusion and swelling are the most common presenting symptoms [1-3]. In our case the presenting symptom was abdominal pain.

Left lobe of the liver is the most common part of the liver to herniate through abdominal wall [5]. This hernia may progress to an incarcerated incisional hernia [7,8]. Median sternotomy for coronary artery bypass [3,9] (this is the surgery in this case), midline laparotomy for trauma, intestinal obstruction [7], orthotopic liver transplantation [10], open cholecystectomy [11] and for choledochotomy to remove liver hydatid cyst [12]. Right sub costal incision for open cholecystectomy and right flank incision via a retroperitoneal approach for nephrectomy, [8] are the comments operations complicated by liver hernia. Briffaut and colleagues report an entity described in neonatal period known as exclusive hepatocele, in which the liver is part of omphalocele contents [13].

Transabdominal ultrasound, CT scan and magnetic resonance imaging can usually appropriately determine liver as the hernia content [1-3,5,9,14]. CT scan confirmed left lobe of liver as a content of incisional hernia in our case. Conservative therapy should be considered first in these rare patients, especially asymptomatic patients and those whose symptoms were minimal [3,9]. In this case we were able to control the symptoms with symptomatic treatment. However, surgical therapy may be an option for patients with more severe complaints [7].

Conclusion

Left lobes of liver rarely herniate through abdominal extension of sternotomy incision following CABG (Coronary Artery Bypass Grafting). A CT scan can confirm the diagnosis. Conservative treatment is usually successful.
