Idealized Model of Mineral Infillings in Bones of Fossil Freshwater Animals, on the Example of Late Triassic Metoposaurs from Krasiejów (Poland)

Bodzioch A*

Department of Biosystematics, Opole University, Poland

*Corresponding author: : Adam Bodzioch, Department of Biosystematics, Opole University, ul. Oleska 22, 45-052 Opole, Poland

Received: December 12, 2014; Accepted: February 24, 2015; Published: February 27, 2015

Abstract

Pore spaces preserved in bones are not studied so often, however they contain a very important information about post-mortem history, which is presented below on the example of microscope observations of fossil aquatic amphibians. Cavities from decay of soft tissues have been filled with a few mineral phases, which form more or less complete sequence related to post-mortem events. The most interesting complete sequence is referred to diagenesis of bones buried together with soft parts in fine-grained sediment of a flooding pool. It starts with the surrounding sediment sucked in by outgoing gas bubbles created during bacterial decomposition of soft tissues. Next two generations of infillings (pyrite, substituted in places by siderite, and granular sparite) have been interpreted as a result of sulfate and iron reducing bacteria activity. The two last generations (blocky sparite and barite) have been interpreted as chemical precipitates. Blocky sparite crystallized from pore solution being in equilibrium with respect to carbonates. Barite evidences shift in pore water chemistry (supersaturation with respect to sulfates), according to progressive evaporation of a flooding pool.

Keywords: Metoposaurus; Triassic; Bone; Diagenesis; Taphonomy

Abbreviations

UOBS: Catalogue Acronym of Bones from the "Trias" Documentation Site in Krasiejów, collected at the Opole University in the years 2000-2007; UOPB: Catalogue acronym of bones from the "Trias" Documentation Site in Krasiejów, collected at the Opole University since the year 2008; SEM: Scanning Electron Microscope; EDS: Energy Dispersive Spectroscopy

Introduction

Diagenesis of bones is not an extensively studied topic, apart from remains of selected terrestrial creatures including archaeological materials [1-7] and dinosaurs [8-10]; in addition, alterations of bone tissue are the main topics [1-16]. Rare analysis of infillings of intrabone spaces are also strongly restricted to archaeological [11] and dinosaurian remains [17,18], while similar studies of other vertebrates are rather unique [19-21]. Thus, an introduction to interpretation of diagenetic events, based on a sequence of mineral phases filling pore spaces in bones of aquatic animals, is the main purpose of this paper.

The study has been carried out on metoposaurs: large, freshwater amphibians living in the Triassic times. Their fossils are best known from Germany [22,23] and Poland [24], where they occur in lacustrine or alluvial plain deposits of the Carnian-Norian age. Paleontological knowledge of those animals is quite broad within the realm of osteology [25,26] and rapidly developing osteohistology [27- 32]. Post-mortem history of metoposaurian bones is still unknown apart from the pioneer publication [33], in which the origin of the metoposaur rich bone bed has been explained on the ground of diagenetic studies. Tissue of analysed bones underwent partial dissolution, recrystallization, replacing and cracking, and intrabone spaces have been completely or nearly completely filled with various mineral phases. Full taphonomic analysis is not yet complete, but simple observations are also valuable for answering certain questions and creation of general hypotheses. Microscope evidence of a sequence of diagenetic events is the first of many necessary steps to be taken in any taphonomic analysis of bones, however only this step is described below. A complete sequence of infillings is referred to biogeochemically induced diagenesis of bones, which have been buried together with soft tissues.

Materials and Methods

The studied material has been collected from the lower bone horizon of the "Trias" Documentation Site in Krasiejów [24,33,34], during excavation field works organized and conducted by the Laboratory of Paleobiology of the Opole University since the year 2000. Bones occur in about 0,8 m thick, grey to red unstructured clay/mud layer, only slightly lithified, which is underlain by red paleosoil and covered in places by thin (0-10 cm), discontinuous limestone of pedogenic origin. The sediment consists of clay minerals (illite, smectite, chlorite and palygorskite), subordinate grains of quartz, muscovite, feldspar, and some heavy minerals [35]. General sedimentologic and diagenetic characteristics show that the bone bed has been deposited as a mud flow [36] in an ephemeral flooding pool [33].

A skull, lower jaw, clavicle, interclavicle, 2 ribs, 8 long bones and 20 vertebral intercenters of metoposaurs were selected to make 76 thin sections (for both osteohistological and diagenetic purposes), which have been prepared at the Institute of Geology of the A. Mickiewicz University in Poznan (Poland) and at the Steinmann Institute für Paläontologie (Bonn University, Germany). The thin sections were examined with a standard petrographic microscope (Olympus Provis AX70) equipped with a digital camera. Simple SEM and EDS analyses have been additionally done to verify petrographic identification of mineral phases using Hitachi S-3700N apparatus.

Results and Discussion

Primary pore spaces inside studied bones include medullary cavities, erosional rooms, components of the vascular system (nutrition vessels, primary and secondary osteons), and osteocyte lacunae together with Volkmann canals. Mineral infillings consist of surrounding sediment, pyrite, siderite, calcite and barite, however, the amount of particular type of infilling may vary in wide ranges among the bones. Only calcite occurs in every bone, and sometimes is the only mineral phase. In other bones, calcite is accompanied by one or more minerals. Sometimes, mineral infillings form a sequence, which is best developed in large medullary cavities and erosional rooms, starting from sediment and following by pyrite, siderite and calcite, and ending with barite. At the same time, small pore spaces in compact bone are usually filled with single mineral phase (pyrite or calcite) or with a pyrite-calcite association. Variation in the development of mineral infillings results from secondary deposition of bones coming from various primary diagenetic environments, and from different post-mortem history of particular specimens and their bones. The complete sequence refers to bones, which have been interpreted as buried together with soft tissues.

The complete sequence starts with surrounding sediment, which fills large vessels going through the cortex to internal cavities (Figure 1) and, in the cavities, it forms a thin, nearly isopachous padding around their surface (Figure 2). In all cases of infillings, sediment is cemented by calcium carbonate and, inside the cavities, additionally by pyrite.

Figure 1: General osteohistological and diagenetic features of vertebral intercenters (UOPB1003, thin section, plane polarized light). The sediment fills a main nutrition vessel (NV) going through the cortex to inner part of the vertebrae. Medullary cavities (M) are filled with sediment (white M), sediment and then calcite (black M), or with sediment, then pyrite (now weathered, black areas) and then calcite (bottom-right part of the photo). T: trabeculae that form spongy bone. Within the cortex, primary osteons are visible as oval structures (po). They are filled with the sediment (if connecting surface of the cortex), pyrite (black) and calcite (light colored areas).



    Figure 1:  General osteohistological and diagenetic features of vertebral
intercenters (UOPB1003, thin section, plane polarized light). The sediment
fills a main nutrition vessel (NV) going through the cortex to inner part of the
vertebrae. Medullary cavities (M) are filled with sediment (white M), sediment
and then calcite (black M), or with sediment, then pyrite (now weathered,
black areas) and then calcite (bottom-right part of the photo). T: trabeculae
that form spongy bone. Within the cortex, primary osteons are visible as oval
structures (po). They are filled with the sediment (if connecting surface of the
cortex), pyrite (black) and calcite (light colored areas).

Figure 2: Sediment padding (S) in spongy bone of the vertebral intercentrum UOPB 1009 (thin section, cross polarized light), followed by pyrite (black lines) and calcite (C). Densely packed pyrite framboids are visible in the rectangle.



    Figure 2:  Sediment padding (S) in spongy bone of the vertebral intercentrum UOPB 1009 (thin section, cross polarized light), followed by pyrite (black lines) and calcite (C). Densely packed pyrite framboids are visible in the rectangle.

Two modes of infiltration of sediment into bone interior can be discussed: hydrodynamic washing in, or sucking in by vacuum created by outgoing gas bubbles originated during decomposition of soft tissues. In the first case, the sediment must be deposited gravitationally at the bottom surface of cavities; isopachous forms of sediment envelopes may have arisen as a result of rolling bones along the bottom, which was impossible because of quiet water environment [34]. Therefore, vacuum seems to be the only force counteracting gravity that allowed clay particles to adhere uniformly to the entire surface of cavities.

Pyrite makes the second generation of infillings, where sediment is present, or the first generation in other cases of its occurrence. Apart from admixture in sediment infillings, it occurs as (1) more or less continuous cover on sediment envelopes (Figure 2,3) or bone tissue (where sediment is absent), separating them from next generation calcite (Figure 4), as (2) inclusions of framboidal forms in the calcite cement (Figure 5), or as (3) mineral filling small pores within the cortex (Figure 6,7). In the last case, pyrite can be associated by calcite.

Figure 3: The same as in Figure 2, SEM image. Weathered pyrite (WP) is visible as white areas between the sediment and calcite.



    Figure 3:  The same as in Figure 2, SEM image. Weathered pyrite (WP) is visible as white areas between the sediment and calcite.

Figure 4: Pyrite covering directly bone tissue (black areas), and followed by two calcite generations: granular (GS) and blocky sparite (BS). Thin section, plane polarized light, vertebral intercentrum UOPB1009.



    Figure 4:  Pyrite covering directly bone tissue (black areas), and followed by two calcite generations: granular (GS) and blocky sparite (BS). Thin section, plane polarized light, vertebral intercentrum UOPB1009.

Figure 5: Framboidal pyrite floating in granular sparite (best visible in the center). Thin section, plane polarized light, vertebral intercentrum UOPB1009.



    Figure 5:  Framboidal pyrite floating in granular sparite (best visible in the center). Thin section, plane polarized light, vertebral intercentrum UOPB1009.
