Austin Surg Case Rep. 2019; 4(1): 1032.
Sigmoid Colon Perforation as a Result of a Migrated Intrauterine Device: A Case Report and Literature Review
Kovalev V1* and Gudata H2
¹College of Osteopathic Medicine, Western University of Health Sciences, USA
²Department of Trauma and Acute Care Surgery, California Hospital Medical Center, USA
*Corresponding author: Kovalev V, College of Osteopathic Medicine, Western University of Health Sciences, USA
Received: October 11, 2019; Accepted: November 13, 2019; Published: November 20, 2019
A 23-year-old female patient presented to the emergency department with abdominal pain two years after placement on a copper-T intrauterine device. Initial computerized tomography scan revealed an IUD perforating the posterior wall of the uterine wall. The device was removed via the transvaginal approach. The patient returned three days later with worsening abdominal pain with multiple intra-abdominal abscesses on CT. She was treated surgically and recovered well. Extrauterine organ involvement due to IUD migration is a well attested occurrence in medical literature. Approaches of IUD removal and management of associated injuries involve endoscopic, laparoscopic and hysteroscopic techniques depending on the specific location of the IUD.
Keywords: Intrauterine device; Perforation; Migration; Peritonitis; Sigmoid colon; Abscess; Laparoscopy
The Intrauterine Device (IUD) has become a common method of long-term contraception, with increasing rates of use in the United States . Migration of the IUD and uterine perforation represents one of the more serious complications. Reported uterine perforation rate is 1.4 per 1000 insertions for levonorgestrel releasing IUDs and 1.1 per 1000 insertions for copper IUDs within 12 months after initial placement . Uterine perforations however can take place decades after placement . Breast-feeding at the time of insertion is wellinvestigated risk factor for uterine perforation. Studies report that the risk is up to 6 to 10 times higher if a woman is breast-feeding at time of insertion . This may be due to a thinner posterior uterine wall during lactation. The migrated IUD may be found in the rectum , sigmoid , small intestine , appendix , urinary bladder , ovary  and small bowel mesentery . Management of a migrated IUD depends on the location or the IUD, structures involved and patient symptomology. Various techniques for the management removal and an IUD and repair of associated injuries have been reported and include employment of endoscopic , laparoscopic  and hysteroscopic  approaches. Case reports exist where asymptomatic patients with no significant organ injuries are treated conservatively . We present a rare case of a missed sigmoid injury due to an IUD perforation and describe subsequent management.
A 23-year-old female, gravida three, para three, presented to the Emergency Department (ED) with epigastric abdominal pain for two days which later migrated to the right lower quadrant. Her history included three Cesarean sections and placement of a copper-T IUD two years prior. She denies any fever, nausea, vomiting, diarrhea, vaginal bleeding, vaginal discharge or urinary complaints. In the ED the patient was afebrile with right lower quadrant tenderness on exam but no rebound tenderness or guarding. The white blood cell count was 17.1 thousand/μL and pregnancy test was negative. The abdominal CT scan report noted an IUD which was implanted in the posterior uterine wall with the horizontal part of the T-shape perforating the uterine body posteriorly. No inflammatory changed were reported on CT with a normal appendix. The Obstetrics and Gynecology service was consulted, and the physician deemed it safe to remove the malpositioned IUD trans-vaginally. The IUD strings were easily visualized, and the IUD was removed with no immediate complications. The patient was discharged home with instructions to follow-up with her primary care physician in one day.
On the third day after her discharge the patient returned to the ED with worsening lower abdominal pain and watery diarrhea. She had a fever of 38.9 Celsius and her abdominal exam revealed the lower abdominal tenderness, but now with guarding. Her white blood cell count was 22.9 thousand/μL. A repeat abdominal CT scan revealed fluid collections and fat stranding around the uterus and in right lower quadrant, as well as multiple small abscesses posterior to the uterus and around the cecum. The appendix was measured at 1.3-centimeter diameter (Figure 1). The surgical service was then consulted. Upon secondary review of the original CT scan from 3 days prior it was discovered that the horizontal position of the copper-T IUD is actually resting within the lumen of the sigmoid colon (Figure 2). It was hypothesized that the cause of the patient’s original abdominal pain and intra-abdominal infection was sigmoid perforation caused by the migrated IUD. The patient was taken to the operating room for laparoscopic drainage of intra-abdominal abscesses. Intra-operative findings included extensive omental, small bowel and cecal inflammation. No obvious source of infection or bowel injury was noted. The appendix was not visualized due to significant inflammation of tissues. Multiple abscesses were drained, and a Jackson-Pratt drain was placed. The patient recovered well after surgery. She was kept on antibiotics and was discharged home after ten days.
Figure 1: Retro-uterine abscess, transverse view (left). Fluid collections in pelvis and right lower quadrant abscesses, coronal view (right).
Figure 2: IUD perforating posterior wall of uterus with horizontal portion of the IUD resting in the lumen of the sigmoid colon (transverse view, coronal view and sagittal view).
The IUD has become a common method of contraception with 13.9% of women using this method around the world . IUDs for contraception were first introduced in 1909 by Richter  and then were further developed by Gräfenberg  in the 1920s. There was a resurgence of their use in 1959 when flexible plastic IUDs were introduced to the market.
Although rare, our literature review found seventy-seven casereports in the international literature, with the most remote report of a Gräfenberg ring migration dating back to 1933 . The most commonly reported organ to be involved are the rectum [5,18-23], comprising 21 of 77 case reports, and the sigmoid colon [24-29], comprising 20 of the 77 case reports. However, reports of migration to the ileum , jejunum , appendix , urinary bladder , ovary  and small bowel mesentery  were also found. When a bowel perforation occurs a triad of abdominal pain, fever, and intermittent diarrhea have been described , which were all present in this patient. However, in some patients an extrauterine IUD is an incidental finding with no obvious symptoms . Complications of an extrauterine IUD include embedment within the bowel wall with a potential risk of bowel perforation, appendicitis , small bowel obstruction [35,36] and two cases where an IUD caused a colocolic fistula [37,38] were also found.
Various approaches to extraction of the IUD and management of associated injuries have been implemented. These approaches depend on the location of the IUD, extent of injuries, acuity of the presentation and patient symptomology. If the IUD is embedded within the rectal or sigmoid wall then removal via endoscopy is feasible in select cases [21,23]. The mucosal defect can then be closed with hemoclips  or endoscopic overstitching . If the IUD is close enough to the anal verge the extraction can be performed during a rectal examination under general anesthesia . Commonly laparoscopic removal is necessary if a significant bowel injury is suspected  or a bowel resection is required. Hysteroscopic removal is feasible if the body of the IUD is primarily embedded with within the uterine wall . Successful removal of an IUD which was embedded in the small bowel mesentery via single-site laparoscopic approach is also reported .
Our care report is unique in that it presents the consequences of a sigmoid perforation caused by a dislodged IUD removed via the transvaginal approach. This case is a prime example that an IUD which has migrated outside the uterine cavity must be assumed to involve intra-abdominal or pelvic organs until proven otherwise. Management of an extra-uterine IUD must involve a multidisciplinary approach as safe extraction and repair of associated injuries may involve the surgical, gynecological and urological services.
Migration of the IUD can cause potentially life-threatening complications. We present a case of a 23-year-old female who presented with sigmoid perforation causing pelvic and right lower quadrant abscesses after a trans-vaginal removal of a migrated IUD. Careful evaluation of the patient, involvement of the multidisciplinary team, identification of the exact location of the IUD and associated organ involvement is imperative to the proper management of this complication. An extrauterine position of any portion of an IUD must be assumed to involve any of the intra-abdominal or pelvic organs until proven otherwise.
- Mosher WD, Moreau C, Lantos H. Trends and determinants of IUD use in the USA, 2002-2012. Hum Reprod. 2016; 31: 1696-702.
- Heinemann K, Reed S, Moehner S, Minh TD. Risk of uterine perforation with levonorgestrel-releasing and copper intrauterine devices in the European Active Surveillance Study on Intrauterine Devices. Contraception. 2015; 91: 274.
- Ples L, Sima RM, Moisei C, Ionescu CA. An intrauterine contraceptive device: where did we find it after 29 years of insertion? A case report. J Pak Med Assoc. 2017; 67: 131-133.
- Berry-Bibee EN, Tepper NK, Jatlaoui TC, et al. The safety of intrauterine devices in breastfeeding women: a systematic review. Contraception. 2016; 94: 725.
- Ye H, Huang S, Zhou Q, et al. Migration of a foreign body to the rectum: A case report and literature review. Medicine (Baltimore). 2018; 97.
- Takahashi H, Puttler M, Hong C, Ayzengart L. Sigmoid colon penetration by an intrauterine device: a case report and literature review. Mil Med. 2014; 179: 127-129.
- Torres-Cepeda D, Reyna-Villasmil E. [Small bowel perforation by an intrauterine device]. Gastroenterol Hepatol. 2016; 39: 495-496.
- Kus E, Swierczewski A, Pasinski J, et al. [Intrauterine contraceptive device in an appendix--a case report]. Ginekol Pol. 2012; 83: 132-135.
- Sepúlveda WH, Ciuffardi I, Olivari A, Gallegos O. Sonographic diagnosis of bladder perforation by an intrauterine device. A case report. J Reprod Med. 1993; 38: 911-913.
- Verma U, Verma N. Ovarian embedding of a transmigrated intrauterine device: a case report and literature review. Arch Gynecol Obstet. 2009: 280: 275-278.
- Singer T, Nizam A, Shay A, Andrews R, Divon MY. Single-Site Laparoscopy for Management of Perforated Intrauterine Device with Small Bowel Mesentery Implantation. J Minim Invasive Gynecol. 2015; 22: S214.
- Huang X, Zhong R, Zeng L, et al. Chronic nodules of sigmoid perforation caused by incarcerated intrauterine contraception device. Medicine (Baltimore). 2019; 98: e14117.
- Markovitch O, Klein Z, Gidoni Y, Holzinger M, Beyth Y. Extrauterine mislocated IUD: is surgical removal mandatory? Contraception. 2002; 66: 105-108.
- United Nations Department of Economic and Social Affairs. World contraceptive patterns 2013. United Nations Department of Economic and Social Affairs; 2015. New York, NY.
- Richter R. [A means of preventing conception]. Deutsch Med Wochenschr. 1909; 35: 1525.
- Gräfenberg E. [The intrauterine method of contraception.] Proceedings of the Third World League for Sexual Reform Congress, London 1929. London, UK: Kegan Paul, Trench, Turner and Company; 1929; 166-175.
- Murphy MC. Migration of a Gräfenberg ring. Lancet. 1933; 2: 1369-1370.
- Shah K, Molmenti EP, Coppa GF, Procaccino JA, Angel LP. Rare presentation of an intrauterine device migration into the rectum. Am Surg. 2010; 76: 243- 244.
- DiPaola L, Wonaga A, Dardanelli M, Viola L. Intrauterine device in the rectal cavity. Rev Esp Enferm Dig. 2017; 109: 290.
- Eichengreen C, Landwehr H, Goldthwaite L, Tocce K. Rectal perforation with an intrauterine device: a case report. Contraception. 2015; 91: 261-263.
- Chandrasekar TS, Gokul BJ, Yogesh KR, et al. A new endoscopic method of retrieval of a migrated and transmurally embedded intrauterine contraceptive device in the rectum. Indian J Gastroenterol. 2016; 35: 489-491.
- Bello OO, Ayandipo OO, Olayide RO. Case report: Retrieval of an intrauterine contraceptive device penetrating through the wall of the rectum. Ann Ib Postgrad Med. 2018; 16: 174-176.
- Al Sahaf MA, Bseiso BF, Al-Momen SA, Meshikhes AN. Endoscopic removal of an incidentally discovered intrauterine contraceptive device eroding into the rectum. BMJ Case Rep. 2019; 12.
- Ali N, Zarin M. Retrieval of Misplaced Intrauterine Device from Sigmoid. J Coll Physicians Surg Pak. 2018; 28: 717-718.
- Yamanaka W, Dejesús Núñez JA, Acosta Chamorro AI, Ayala Benítez CB. [Uterine and sigmoid colon perforation due to an intrauterine device]. Cir Esp. 2012; 90: 338-339.
- Al-Mukhtar RS, Al-Ali JA, Amin MM, Al-Sumait BM. Migration of an intrauterine contraceptive device into the sigmoid colon. Saudi Med J. 2009; 30: 561-563.
- Baakdah H1, Asswad AF, Tulandi T. Sigmoid penetration by an intrauterine device. J Minim Invasive Gynecol. 2005; 12: 384.
- Juárez-Azpilcueta A, Romero-Hernández S, Motta-Martínez E. [Uterine and rectosigmoid perforation secondary to placement of an intrauterine device, case report with literature review]. Gac Med Mex. 2003; 139: 73-75.
- Sentilhes L, Lefebvre-Lacoeuille C, Poilblanc M, Descamps P. Incidental finding of an intrauterine device in the sigmoid colon. Eur J Contracept Reprod Health Care. 2008; 13: 212-214.
- Velázquez Velasco JR, Vilchis P, Nevarez RA, Kably A. [Uterine and jejunum perforation due to intrauterine device. A report of a case and literature review]. Ginecol Obstet Mex. 2006; 74: 435-438.
- Peng L, Wei S, Li X, et al. Endoscopic removal of a migrated intrauterine contraceptive device in the rectum assisted by Overstitch defect closure. Endoscopy. 2019; 51: 276-277.
- Weng SF, Chen HS, Chen YH, Lee JN, Tsai EM. Rectum penetration that was caused by the displacement of an intrauterine device and mimicked rectal endometriosis. Taiwan J Obstet Gynecol. 2011; 50: 375-376.
- Key TC, Kreutner AK. Gastrointestinal complications of modern intrauterine devices. Obstet Gynecol. 1980; 55: 239-244.
- Serra I. Appendicitis caused by an intrauterine contraceptive device. Br J Surg. 1986; 73: 927-928.
- Jones D. Young woman with abdominal pain. Small bowel obstruction caused by IUD migration. Ann Emerg Med. 2014; 64: 423-425.
- De Villiers H, Rosenstein F. Intestinal obstruction following perforation of the uterus with an intrauterine contraceptive device. Am J Obstet Gynecol. 1966; 96: 592-593.
- Weerasekera A, Wijesinghe P, Nugaduwa N. Sigmoid colocolic fistula caused by intrauterine device migration: a case report. J Med Case Rep. 2014; 8: 81.
- Pirwany IR, Boddy K. Colocolic fistula caused by a previously inserted intrauterine device. Case report. Contraception. 1997; 56: 337-339.
Citation: Kovalev V and Gudata H. Sigmoid Colon Perforation as a Result of a Migrated Intrauterine Device: A Case Report and Literature Review. Austin Surg Case Rep. 2019; 4(1): 1032.
